IOME 2500 Gallon 64" UL Single Wall AST for Fuel and Oil - Steel Painted White(UL142)

Our UL single wall B-skid tanks are manufactured in Clinton, IL. They are made with 7-gauge steel to ensure safe storage of flammable or combustible fluids.

These tanks come standard with full-length, integral skids. Easily maneuver empty tanks by the skids, lifting with a fork lift, or hoisting machinery using the lifting hook on top of the tank.

The 2500 Gallon UL142 Single Wall Skid Tanks bung openings include five(5) 2” openings, one(1) 6" male threaded opening, and one(1) 1” drain opening. A reinforced steel plate is welded on top with a 2" opening for the pump to mount to for extra stability.

2500 Gallon Tank:
64" Diameter x 180" Long, Max Capacity ≈2500 Gallons

• (1) 2" reinforced pump opening
• (4) 2" openings for gauge, pressure vacuum vent, fill cap, and an extra opening
• (1) 6" opening for emergency vent
• (1) 1" drain opening on the side at the bottom
