IOME 2000 Gallon 65" Double Wall AST for Fuel and Oil - Steel Painted White(UL142)

Our UL double wall B-skid tanks are manufactured in Clinton, IL. They are made with 7 and 10-gauge steel to ensure safe storage of flammable or combustible fluids.

These tanks come standard with full-length, integral skids. Easily maneuver empty tanks by the skids, lifting with a fork lift, or hoisting machinery using the lifting hook on top of the tank.

The 1500 Gallon UL142 Double Wall Skid Tanks bung openings include six(6) 2” openings, Two(2) 6" male threaded opening, and one(1) 1” drain opening. A reinforced steel plate is welded on top with a 2" opening for the pump to mount to for extra stability.

2000 Gallon Tank:
65" Diameter x 144" Long, Max Capacity ≈1963 Gallons

• (1) 2" reinforced pump opening
• (4) 2" openings for gauge, pressure vacuum vent, and fill cap
• (1) 2" opening for leak gauge
• (2) 6" opening for emergency vent
• (1) 1" drain opening on the side at the bottom(interstitial only)
